Broadband FC / PC Fiber Optic Connector Singlemode Fiber Assembled

Name: Broadband FC PC Fiber Optic Connector Singlemode Fiber Assembled
Brand: FOCC
Price: 1 USD

Brand Name : FOCC

Model Number : FOCC - 008

Certification : RoSH, CE, SGS

Place of Origin : China

MOQ : 10 Pieces

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : Delivery Time 5000 Pieces Of Capacity Per Month

Delivery Time : 5 - 7 Working Days

Packaging Details : Box of 12 Individually Bagged Connectors With Optional Termination Aid

Fiber Type : Simplex

Fiber Compatibility : Singlemode, Multimode

Insertion Loss : < 0.2dB

Polishing : PC, UPC, APC

Operating Temperature : - 40°C ~ + 75°C

Certificates : UL, CE, ISO9001, RoHS

Contact Now

Broadband FC / PC Fiber Optic Connector Singlemode Fiber Assembled

FOCC this kind of FC connector is a fiber optic connector with a threaded body, which was designed for use in high vibration environments. It is commonly used with both single-mode optical fiber and polarization maintaining optical fiber. The FC fiber optic connector has been standardized in a FOCIS 4 (Fiber Optic Connector Intermateability Standards) in EIA/TIA-604-04. FC is an acronym for Fiber Connector " ferrule connector " or " fiber channel".

Specifications

Item	Singlemode	Multimode
Insertion Loss	PC < 0.3dB APC < 0.2dB	PC < 0.3dB
Return Loss	PC > 45dB APC > 60dB	PC > 25dB
Insert-pull Test	1000 times < 0.3dB
Operating Temperature	- 40°C ~ + 75°C
Ceramic Ferrule Spec	125.5um concentricity : < 1um	127um concentricity : < 3um
Polish Type	PC / APC(9 / 125um)	PC (50 / 125um,62.5 / 125um)

Features

Low insertion loss;
Corrosion resistant body;
Inner key and key ring styles available;
Variety of boot types and colors;
Precision mechanical dimension;
Meets Telecordia-GR-326-CORE specifications;
Ultra low back reflection;
One Piece with pre-domed ceramic ferrule is designed for easy assembly.

Applications

LAN & WAN;
CATV fiber optic links;
Network;
Broadband;
Telecommunications.

Broadband FC / PC Fiber Optic Connector Singlemode Fiber Assembled

Shipping Via Those Follow Tools

FOCC Optic Fiber Connector Quality

Broadband FC / PC Fiber Optic Connector Singlemode Fiber Assembled

Notes:

Prices and specifications are subject to change without notice.
FOCC is not responsible for typographical or photographic errors.

MORE INFORMATION please contact us focc@fiberfocc.com directly, your choices are under our best service.
