Armored Ethernet Fiber Optic Patch Cables SC to FC Multi-Mode Duplex Patch Cord
FOCC is a professional manufacturer of singlemode and multimode fiber patch cables. All our 1M SC to SC Multimode Duplex OM1 62.5/125 fiber patch cables are made of finest quality material. If you require custom length and color cables, email us your requirements.
Multimode Fiber Patch Cable Specifications
| Mode | Multimode |
| Connector A | Duplex SC |
| Connector B | Duplex FC |
| Cable Diameter | 2.0mm |
| Core Size | 62.5 / 125 |
| Polish | PC |
| Manufacturer | FOCC |
| Warranty | Lifetime |
Feature
100% optically tested;
Factory terminated for superior performance;
Meets or exceeds industry standards for Return Loss and Reflectance;
Segmented boot for bend strain relief;
Available in simplex or duplex with a wide variety of connectors;
Insertion loss testing performed on every assembly;
Zipcord jacket with aramid yarn strength members;
Customized assemblies can ship in as little as 5 days.
Application
Long haul trunk, Metro and access system;
CATV, LAN, WAN;
ODF, FTTX, FTTH;
Telecommunication network;
Optical test equipment.
Chromatogram Options
Patch Cables Specifications
| Specification | Unit | FC,SC, LC/Armored Cables | ST, MU | MT-RJ, MPO | E2000 |
| SM | MM | SM | MM | SM | MM | SM |
| PC | APC | UPC | PC | PC | UPC | PC | PC | UPC | PC | UPC |
| Insertion loss | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.3 |
| Return loss | dB | ≥45 | ≥45 | ≥60 | ≥30 | ≥45 | ≥50 | ≥30 | ≥45 | ≥50 | ≥55 | ≥75 |
| Wavelength | nm | 850,1310 | 850,1310 | 850,1310 | 850,1310 |
| Interchange Ability | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 |
| Vibration | dB | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 |
| Operating Temperature | ℃ | - 40 ~ + 75 | - 40 ~ + 75 | - 40 ~ + 75 | - 40 ~ + 75 |
| Storage Temperature | ℃ | - 40 ~ + 85 | - 40 ~ + 85 | - 40 ~ + 85 | - 40 ~ + 85 |
| Cable Diameter | mm | Φ 3.0 , φ 2.0 , φ0.9 | φ3.0 , φ2.0 , φ0.9 | φ3.0 , φ2.0 , φ0.9 | φ3.0 , φ2.0 , φ0.9 |
Fiber Patch Cables Quality Guarantee
Pricing for inquired please email us at focc@fiberfocc.com freely we can try our best service for you.
